Опыт использования утилиты logman для сбора метрик производительности приложения в Windows

import os
import logging
import random
import time
import subprocess
import glob
import multiprocessing


CPU_USER_COUNTER = '"Processor(_Total)% User time"'
CPU_APP_COUNTER = '"Process({app})% Processor time"'
MEMORY_COUNTER = '"Process({app})Working Set"'
APP_PLACEHOLDER = '{app}'


class PerflogManager(object):

    def __init__(self, app_name, precision, results_dir, max_mem=1, interval=1):
        """
        Args:
            app_name: name of the application without "exe" extention
            precision: amount of
            results_dir: output folder
            max_mem: this value is used to calculate % from total avaliable memory for further plotting
            interval: interval which will be used as "-si" logman option value
        """

        self._app_name = app_name
        self._precision = precision
        self._counters = { 'cpu.usage': '{cpu_user} {cpu_app}'.format(cpu_user=CPU_USER_COUNTER,
                                                                      cpu_app=CPU_APP_COUNTER).replace(APP_PLACEHOLDER, app_name),
                           'mem.usage': MEMORY_COUNTER.replace(APP_PLACEHOLDER, app_name) }
        self._results_dir = os.path.normpath(results_dir)
        self._raw_dir = os.path.join(self._results_dir, 'raw')
        self._final_dir = os.path.join(self._results_dir, 'csv')
        self._interval = interval
        self._max_mem = max_mem
        self._collectors = []
        if not os.path.exists(self._results_dir):
            os.makedirs(self._results_dir)
            os.makedirs(self._raw_dir)
            os.makedirs(self._final_dir)
            logging.info('Directory "{path}" for logman results has been created.'.format(path=self._results_dir))
        logging.info('Performance logman manager has been created for "{}" application.'.format(self._app_name))


    def init_collectors(self):
        """
        Creates collectors by "logman create" command
        """

        logging.info('Creating collectors set...')
        for lang in self._counters:
            for idx in range(self._precision):
                collector = '{app}-{collector}-{id}'.format(app=self._app_name,
                                                            collector=lang,
                                                            id=idx)
                output = os.path.join(self._raw_dir, collector + '.csv')
                self.__create(collector, self._counters[lang], output)
                self._collectors.append(collector)


    def start_all(self):
        """
        Starts all the collectors from self._collectors list
        """

        for collector in self._collectors:
            self.__start(collector)
            time.sleep(random.uniform(0.1, 0.9))


    def stop_all(self):
        """
        Stops and deletes all initiated collectors from self._collectors list
        """

        for collector in self._collectors:
            self.__stop(collector)
            self.__delete(collector)


    def cleanup(self):
        """
        Cleans raw_dir directory which contains unprocessed csv file from logman
        """
        logging.info('Cleaning results directory from unnecessary files.')
        for collector in self._collectors:
            csv = os.path.join(self._raw_dir, '{}.csv'.format(collector))
            if os.path.isfile(csv):
                os.remove(csv)


    def process_csv(self):
        """
        Composes and formats data from all counters for further plotting
        """

        for lang in self._counters:
            final_output = os.path.join(self._final_dir, '{}.csv'.format(lang))
            self.__compose_csv(final_output, lang)
            self.__format_data(final_output)


    def __compose_csv(self, output, counter):
        """
        Concatenates gathered csv data to one file
        """

        logging.info('Composing file "{}".'.format(output))
        try:
            with open(output, 'a') as outfile:
                for csv in glob.glob(os.path.join(self._raw_dir, '*{}*'.format(counter))):
                     with open(csv, 'r') as file:
                        outfile.writelines(file.readlines()[1:]) # Get rid of a file header with service info
            logging.info('File {} successfully created.'.format(output))
        except (FileNotFoundError, IOError) as e:
            logging.error('Failed to compose file {file}: {exception}'.format(file=output,
                                                                              exception=e))


    def __format_data(self, file):
        """
        Sorts data after self.__compose_csv function and calculates % of CPU and Memory
        """

        try:
            with open(file, 'r') as csv:
                raw_data = csv.readlines()
            with open(file, 'w') as csv:
                sorted_data = [line.replace('"', '').replace(',', ';')
                            for line in sorted(raw_data)
                            if '" "' not in line]
                csv_data = []
                if 'cpu' in file:
                    for line in sorted_data:
                        time, cpu_user, cpu_app = line.split(';')
                        cpu = (float(cpu_user) * float(cpu_app)) / (multiprocessing.cpu_count() * 100)
                        csv_data.append('{};{:.2f}n'.format(time, cpu))
                if 'mem' in file:
                    for line in sorted_data:
                        time, total_memory = line.split(';')
                        mem = float(total_memory) / (self._max_mem * 10000)
                        csv_data.append('{};{:.2f}n'.format(time, mem))
                csv.writelines(csv_data)
        except (FileNotFoundError, IOError) as e:
            logging.error('Failed to process file "{file}": {exception}'.format(file=file,
                                                                                exception=e))


    def __logman(self, cmd):
        """
        Default wrapper for logman commands

        Args:
            cmd: windows command to be executed
        """

        try:
            logging.debug('Running {}'.format(cmd))
            subprocess.check_call(cmd)
        except (subprocess.CalledProcessError, OSError) as e:
            logging.error('Failed to execute command "{}": {}.'.format(cmd, e))


    def __create(self, name, counter, output):
        """
        Creates logman counter

        Args:
            name: uniq name of a collector
            counter: type of the counter (can be taken from perfmon)
            output: csv file for results
        """

        logging.info('Creating collector "{}"'.format(name))
        cmd = 'logman create counter "{name}" -f csv -si {interval} '
              '--v -o "{output}" -c {counter}'.format(name=name,
                                                      interval=str(self._interval),
                                                      output=output,
                                                      counter=counter)
        self.__logman(cmd)


    def __start(self, name):
        """
        Starts logman collector

        Args:
            name: uniq name of a collector
        """

        logging.info('Starting collector "{}".'.format(name))
        cmd = 'logman start {}'.format(name)
        self.__logman(cmd)


    def __stop(self, name):
        """
        Stops logman collector

        Args:
            name: uniq name of a collector
        """

        logging.info('Stopping collector "{}".'.format(name))
        cmd = 'logman stop {}'.format(name)
        self.__logman(cmd)


    def __delete(self, name):
        """
        Deletes logman collector

        Args:
            name: uniq name of a collector
        """

        logging.info('Deleting collector "{}".'.format(name))
        cmd = 'logman delete {}'.format(name)
        self.__logman(cmd)


if __name__ == '__main__':
    logging.basicConfig(level=logging.DEBUG)
    app = 'skype'
    start_time = time.strftime('%Y%m%d-%H%M%S', time.gmtime())
    logman = PerflogManager(app, 3, 'd:/logman-test/')
    logman.init_collectors()
    logman.start_all()
    time.sleep(20)
    logman.stop_all()
    logman.process_csv()
